OpenWRT配置

文章目录

网上的配置抄了很多发现没有用，每个人的需求想法都不一样，理解每个配置的目的才是最主要的

基础设置

  1. Fake-Ip（TUN）模式 + Mixed 网络栈类型 是我用下来速度最快的，建议不要照抄我的，机器不同，可以每个都试一下，找到适合你的
  2. 如果改完之后XXX网站访问不了了，不要着急，不一定是你吧配置改崩了，网站那么多，换个试试呗
  3. 关于DNS，加很多公开的DNS可以提升速度，但是公开的DNS查询有被运营商劫持和泄露的可能，建议全部使用加密的DNS查询，国内外都是
  4. DNS查询结果会缓存，第一次会慢，后续都会从缓存查询，对速度影响很小，速度和安全不能同时兼顾，如果你想要速度，可以直接使用上记路由下发的DNS这是最快的，要安全将所有DNS缓存加密的
  5. 整个配置中唯一的未加密DNS查询是default-nameserver中的119.29.29.29，default-nameserver中的DNS用于解析nameserver和fallbackDNS中的域名，这是必须的，且应该是国内的
  6. nameserver用于没有命中规则的网站，即国内的网站，这里的配置应该全部使用国内DNS
  7. fallback用于命中规则的网站，此处不需要配置任何dns，因为解析在远程处理
  8. 当你发现某个应该直连的网站没有直连时，可以尝试上网搜索这是哪个程序的，之后去这些网站上找到这个程序的规则，并设置为直连
  9. 规则设置，规则应该尽可能精简，规则越多匹配速度越慢，我的设置思想
    • 分流国内流量为直连
    • 需要经常切换的单独分流，比如Netflix，Spotify等
    • 如果存在重复情况，先匹配少量规则再匹配大量规则，参考对Microsoft的分流

https://github.com/ACL4SSR/ACL4SSR/tree/master
https://github.com/blackmatrix7/ios_rule_script

tailscale兼容

  1. 将tailscale的域名tailscale.io,tailscale.com加入到fake-ip-filter，tailscale的DNS查询均不会返回fake-ip
- "+.tailscale.com"
- "+.tailscale.io"
  1. 自定义规则里添加，tailscale直连
- DOMAIN-SUFFIX,tailscale.io,DIRECT
- DOMAIN-SUFFIX,tailscale.com,DIRECT

完整配置

port: 7890
socks-port: 7891
allow-lan: true
bind-address: "*"
mode: rule
log-level: info
ipv6: false
profile:
  store-selected: true
  store-fake-ip: true
unified-delay: true
tcp-concurrent: true
dns:
  enable: true
  ipv6: false
  listen: 0.0.0.0:7874
  fake-ip-range: 198.18.0.1/16
  use-hosts: true
  default-nameserver:
  - 119.29.29.29
  nameserver:
  - https://doh.pub/dns-query
  fake-ip-filter:
  - "*.lan"
  # 此处隐藏
  - "+.tailscale.com"
  - "+.tailscale.io"
    fallback:
  - 1.1.1.1
  - 8.8.8.8
  fallback-filter:
    geoip: true
    geoip-code: CN
    ipcidr:
    - 240.0.0.0/4
  fake-ip-filter-mode: blacklist
  enhanced-mode: fake-ip
rules:
- IP-CIDR,45.121.184.0/24,DIRECT
- DOMAIN-SUFFIX,tailscale.io,DIRECT
- DOMAIN-SUFFIX,tailscale.com,DIRECT

2025/3/23更新

主要更新规则匹配部分

port: 8080
socks-port: 1080
allow-lan: true
bind-address: "*"
mode: rule
log-level: warning
ipv6: false
profile:
  store-selected: true
  store-fake-ip: true
unified-delay: true
tcp-concurrent: true
dns:
  enable: true
  ipv6: false
  listen: '[::]:1053'
  enhanced-mode: fake-ip
  fake-ip-range: 198.18.0.1/16
  use-hosts: true
  default-nameserver:
    - 223.5.5.5
    - 119.29.29.29
  nameserver:
    - https://dns.alidns.com/dns-query
    - https://doh.pub/dns-query
  fake-ip-filter:
    - "*.lan"
    - "*.localdomain"
    - "*.example"
    - "*.invalid"
    - "*.localhost"
    - "*.test"
    - "*.local"
    - "*.home.arpa"
    - time.*.com
    - time.*.gov
    - time.*.edu.cn
    - time.*.apple.com
    - time-ios.apple.com
    - time1.*.com
    - time2.*.com
    - time3.*.com
    - time4.*.com
    - time5.*.com
    - time6.*.com
    - time7.*.com
    - ntp.*.com
    - ntp1.*.com
    - ntp2.*.com
    - ntp3.*.com
    - ntp4.*.com
    - ntp5.*.com
    - ntp6.*.com
    - ntp7.*.com
    - "*.time.edu.cn"
    - "*.ntp.org.cn"
    - +.pool.ntp.org
    - time1.cloud.tencent.com
    - music.163.com
    - "*.music.163.com"
    - "*.126.net"
    - musicapi.taihe.com
    - music.taihe.com
    - songsearch.kugou.com
    - trackercdn.kugou.com
    - "*.kuwo.cn"
    - api-jooxtt.sanook.com
    - api.joox.com
    - joox.com
    - y.qq.com
    - "*.y.qq.com"
    - streamoc.music.tc.qq.com
    - mobileoc.music.tc.qq.com
    - isure.stream.qqmusic.qq.com
    - dl.stream.qqmusic.qq.com
    - aqqmusic.tc.qq.com
    - amobile.music.tc.qq.com
    - "*.xiami.com"
    - "*.music.migu.cn"
    - music.migu.cn
    - +.msftconnecttest.com
    - +.msftncsi.com
    - localhost.ptlogin2.qq.com
    - localhost.sec.qq.com
    - +.qq.com
    - +.tencent.com
    - +.srv.nintendo.net
    - "*.n.n.srv.nintendo.net"
    - +.cdn.nintendo.net
    - +.stun.playstation.net
    - xbox.*.*.microsoft.com
    - "*.*.xboxlive.com"
    - xbox.*.microsoft.com
    - xnotify.xboxlive.com
    - +.battlenet.com.cn
    - +.wotgame.cn
    - +.wggames.cn
    - +.wowsgame.cn
    - +.wargaming.net
    - proxy.golang.org
    - stun.*.*
    - stun.*.*.*
    - +.stun.*.*
    - +.stun.*.*.*
    - +.stun.*.*.*.*
    - +.stun.*.*.*.*.*
    - heartbeat.belkin.com
    - "*.linksys.com"
    - "*.linksyssmartwifi.com"
    - "*.router.asus.com"
    - mesu.apple.com
    - swscan.apple.com
    - swquery.apple.com
    - swdownload.apple.com
    - swcdn.apple.com
    - swdist.apple.com
    - lens.l.google.com
    - stun.l.google.com
    - na.b.g-tun.com
    - +.nflxvideo.net
    - "*.square-enix.com"
    - "*.finalfantasyxiv.com"
    - "*.ffxiv.com"
    - "*.ff14.sdo.com"
    - ff.dorado.sdo.com
    - "*.mcdn.bilivideo.cn"
    - +.media.dssott.com
    - shark007.net
    - Mijia Cloud
    - +.cmbchina.com
    - +.cmbimg.com
    - local.adguard.org
    - +.sandai.net
    - +.n0808.com
    - +.uu.163.com
    - ps.res.netease.com
    - +.pub.3gppnetwork.org
    - geosite:category-games
    - geosite:apple-cn
    - +.vio.vin
    - +.openwrt.ai
    - +.tailscale.com
    - +.tailscale.io
    - geosite:cn
  fallback:
    - 1.1.1.1
    - 8.8.8.8
  fallback-filter:
    geoip: true
    geoip-code: CN
    ipcidr:
      - 240.0.0.0/4
  fake-ip-filter-mode: blacklist
  respect-rules: true
  prefer-h3: false
  use-system-hosts: false
  proxy-server-nameserver:
    - https://dns.alidns.com/dns-query
    - https://doh.pub/dns-query
  direct-nameserver:
    - https://dns.alidns.com/dns-query
    - https://doh.pub/dns-query


proxy-providers:
  Kuromisubs:
    url: ""
    type: http
    interval: 86400
    health-check:
      enable: true
      url: https://www.gstatic.com/generate_204
      interval: 300
    proxy: DIRECT
    header:
      User-Agent:
      - "mihomo"

#proxies:
#  - {name: DIRECT, type: direct, udp: true}

pr: &pr {type: select, proxies: [PROXY, 香港故转, 新加坡故转, 日本故转, 香港自动, 日本自动, 新加坡自动, 美国自动, 香港节点, 日本节点, 美国节点, 全部节点, DIRECT]}
proxy-groups:
  - {name: PROXY, type: select, proxies: [香港故转, 新加坡故转, 日本故转, 香港自动, 日本自动, 新加坡自动, 美国自动, 香港节点, 日本节点, 美国节点, 全部节点, DIRECT]}
  - {name: Microsoft, <<: *pr}
  - {name: Github, <<: *pr}
  - {name: NETFLIX, <<: *pr}
  - {name: Spotify, <<: *pr}
  - {name: MATCH, <<: *pr}
  - {name: 香港节点, type: select, include-all: true, filter: "(?i)港|hk|hongkong|hong kong"}
  - {name: 日本节点, type: select, include-all: true, filter: "(?i)日|jp|japan"}
  - {name: 美国节点, type: select, include-all: true, filter: "(?i)美|us|unitedstates|united states"}
  - {name: 香港故转, type: fallback, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(港|HK|(?i)Hong))^((?!(台|日|韩|新|深|美)).)*$"}
  - {name: 日本故转, type: fallback, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(日|JP|(?i)Japan))^((?!(港|台|韩|新|美)).)*$" }
  - {name: 新加坡故转, type: fallback, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(新|SG|(?i)Singapore))^((?!(港|台|日|韩|美)).)*$"}
  - {name: 香港自动, type: url-test, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(港|HK|(?i)Hong))^((?!(台|日|韩|新|深|美)).)*$"}
  - {name: 日本自动, type: url-test, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(日|JP|(?i)Japan))^((?!(港|台|韩|新|美)).)*$" }
  - {name: 新加坡自动, type: url-test, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(新|SG|(?i)Singapore))^((?!(港|台|日|韩|美)).)*$"}
  - {name: 美国自动, type: url-test, include-all: true, tolerance: 20, interval: 300, filter: "(?=.*(美|US|(?i)States|America))^((?!(港|台|日|韩|新)).)*$"}
  - {name: 全部节点, type: select, include-all: true}

# 规则集
rule-anchor:
  ip: &ip {type: http, interval: 86400, behavior: ipcidr, format: mrs}
  domain: &domain {type: http, interval: 86400, behavior: domain, format: mrs}
  class: &class {type: http, interval: 86400, behavior: classical, format: text}
  yaml: &yaml {type: http, interval: 86400, behavior: domain, format: yaml, path: payload}
rule-providers:
#  ChinaMax: {  <<: *yaml, url: "https://raw.githubusercontent.com/blackmatrix7/ios_rule_script/refs/heads/master/rule/Clash/ChinaMax/ChinaMax_Classical.yaml" }
#  Microsoft: { <<: *yaml, url: "https://raw.githubusercontent.com/blackmatrix7/ios_rule_script/refs/heads/master/rule/Clash/Microsoft/Microsoft.yaml"}
#  Speedtest: { <<: *yaml, url: "https://raw.githubusercontent.com/blackmatrix7/ios_rule_script/refs/heads/master/rule/Clash/Speedtest/Speedtest_No_Resolve.yaml"}
#  GFW: { <<: *domain, url: "https://raw.githubusercontent.com/MetaCubeX/meta-rules-dat/meta/geo/geosite/gfw.mrs"}
#  Game: { <<: *domain, url: "https://raw.githubusercontent.com/MetaCubeX/meta-rules-dat/meta/geo/geosite/category-games.mrs"}


rules:
  - DOMAIN-SUFFIX,mojang.com,PROXY
  - DOMAIN-SUFFIX,vio.vin,DIRECT
  - DOMAIN-SUFFIX,violet.vin,PROXY
  - DOMAIN-SUFFIX,tailscale.io,DIRECT
  - DOMAIN-SUFFIX,tailscale.com,DIRECT
  - GEOSITE,CN,DIRECT
  - GEOIP,CN,DIRECT
  - GEOSITE,CATEGORY-GAME-ACCELERATOR-CN,DIRECT
  - GEOSITE,CATEGORY-GAMES,DIRECT
  - GEOSITE,apple,DIRECT
  - GEOSITE,apple-cn,DIRECT
  - GEOSITE,netflix,NETFLIX,no-resolve
  - GEOSITE,spotify,Spotify,no-resolve
  - GEOSITE,github,Github,no-resolve
  - GEOSITE,onedrive,Microsoft,no-resolve
  - GEOSITE,microsoft,Microsoft,no-resolve
  - MATCH,MATCH

find-process-mode: off
keep-alive-idle: 600
keep-alive-interval: 15
external-ui: ui
external-ui-url: https://github.com/Zephyruso/zashboard/archive/refs/heads/gh-pages.zip
external-controller: '[::]:9090'
secret: "998879"
mixed-port: 7890
redir-port: 7891
tproxy-port: 7892
tun:
  enable: true
  auto-route: false
  auto-redirect: false
  auto-detect-interface: false
  device: nikki
  stack: mixed
  mtu: 9000
  gso: true
  gso-max-size: 65536
  endpoint-independent-nat: false
sniffer:
  enable: false
  force-dns-mapping: false
  parse-pure-ip: false
geodata-mode: false
geodata-loader: standard
geox-url:
  geosite: https://ghfast.top/https://github.com/MetaCubeX/meta-rules-dat/releases/download/latest/geosite.dat
  mmdb: https://ghfast.top/https://github.com/MetaCubeX/meta-rules-dat/releases/download/latest/geoip-lite.metadb
  geoip: https://ghfast.top/https://github.com/MetaCubeX/meta-rules-dat/releases/download/latest/geoip-lite.dat
  asn: https://ghfast.top/https://github.com/MetaCubeX/meta-rules-dat/releases/download/latest/GeoLite2-ASN.mmdb
geo-auto-update: true
geo-update-interval: 30

2025/4/1更新

更新了规则，有效防止DNS泄露

rules:
  - DOMAIN-SUFFIX,mojang.com,PROXY
  - DOMAIN-SUFFIX,vio.vin,DIRECT
  - DOMAIN-SUFFIX,violet.vin,PROXY
  - DOMAIN-SUFFIX,tailscale.io,DIRECT
  - DOMAIN-SUFFIX,tailscale.com,DIRECT
  - GEOSITE,CATEGORY-GAME-ACCELERATOR-CN,DIRECT
  - GEOSITE,CATEGORY-GAMES,DIRECT
  - GEOSITE,apple,DIRECT
  - GEOSITE,apple-cn,DIRECT
  - GEOSITE,netflix,NETFLIX,no-resolve
  - GEOSITE,spotify,Spotify,no-resolve
  - GEOSITE,github,Github,no-resolve
  - GEOSITE,onedrive,OneDrive
  - GEOSITE,microsoft,Microsoft
  - GEOSITE,geolocation-!cn,PROXY,no-resolve
  - GEOIP,private,DIRECT
  - GEOIP,CN,DIRECT
  - GEOSITE,CN,DIRECT
  - MATCH,MATCH

已知问题

HY2节点无法正常访问

相关issue：

https://github.com/MetaCubeX/mihomo/issues/1222

https://github.com/MetaCubeX/mihomo/issues/1911

解决办法：无

Mixed协议栈下，UDP无法正常转发

具体现象表现为所有UDP服务均无法正常访问，Teamspeak连接不上服务器，CS2显示无法连接到任意服务器

相关issue：

https://github.com/MetaCubeX/mihomo/issues/1866

https://github.com/MetaCubeX/mihomo/issues/1632

解决办法：使用System协议栈
